- Condition: New
- Product Type: Belt
- Type: Crochet Knitting Machine
- Production Capacity: 1-1.5m/min
- Place of Origin: Fujian, China (Mainland)
- Brand Name: YITAI
- Model Number: YTW-C 609/B8
- Power(W): 220V
- Knitting Style: Flat
- Knitting Method: Single
- Computerized: No
- Weight: 800KGS
- Dimension(L*W*H): 2000*1200*2050mm
- After-sales Service Provided: Engineers available to service machinery overseas
- Description: Yitai Crochet Machines For Sales, Elastic Bandage Machine,
- Model: YTW-C 609/B8
- Operating Width: 600MM
- Gauge Per Inch: 15,20
- Weft Bars: 3
- Machine Size: 2000*1200*2050mm
- Net Weight: 800 KGS
- Gross Weight: 830 KGS
- Warranty: 1 Year
- Products: Elasic and Non-elastic flat tapes, knitting elastic laces and so on,
Packaging & Delivery
|Packaging Details:||1 elastic crochet machines per standard wooden case. Yitai Crochet Machines For Sales, Elastic Bandage Machine, Machine To Crochet|
|Delivery Detail:||Shipped in 25 days after payment|
Welcome to YITAI Group!
20 years Manufacturer of Weaving Machines.
Agents in South America, India, Indonesia, Bangladesh now. 7 branches in different countries.
More agents in other countries wanted !!!
Join us, benefit both of us !
Yitai Crochet Machines For Sales, Elastic Bandage Machine, Machine To Crochet
Yitai crochet knitting machine has the same model as Italian Comez. Our company started producing crochet knitting machine since 2007. To ensure the quality, company spent heavily on the horizontal machining center imported from USA. All kinds of boxes for Yitai crochet knitting machine are processed on the horizontal machining center to ensure size precision. Core shafts like front/back needle bed/cams/design board wheel are purchased from Taiwan. Other relevant shafts are processed in machining center as long as precision is required.
Unique structure design, easy operation, convenient maintenance, operating in high-speed without noise and oil-leaking. High stability when operation.
8 weft pole, 11 weft pole and design board circulation are adopted to make the tape design has more diversity.
Weft-density drive is operated by multiple sprocket and chain.
Separated device on weft density and rubber manage the warp yarn in different layer, easy to operate, save time and energy.
Double-section rubber feeder idler wheel make sure rubber yarn stable.
Independent oiling feeder system, lubricate machine parts when operation, to ensure machine veracity and lengthen lifespan.
Design board adopts independent variation combination, suitable for different needle number. Design can be adjusted according to different tape construction to produce perfect products.
Multiple groups and multiple creel places provided to attain different tapes’ need.
|COMEZ STYLE||YITAI MODEL|
|Gauge Per Inch||15,20||12,15,20|
|Link Chain Extension||12,12-50,90||12, 12---50||12,12-50,90|
|Speed||1100-1300 rpm||1400 rpm|
|Normal Attachment||rubber feeder, finished product collecting roller on both side, creel, beam holder.|
|Optional Attachment||beam(355*255mm, USD50/PCS), adjustable positive feeder for warp threads, device for loose weft effect on two edges.|
|Back Yarn Creel Ends||300 ends (150 ends left and 150 ends right)||200|
|Back Beam Creel Ends||8-10|
Machine Working Video is Available! Please Contact Us for More Information.
1-1.5M/ min.(Depends on material and weft density)
Elasic and Non-elastic flat tapes, knitting elastic laces and so on.
Warping machine; Festooning machine
1. Best After-sales service for customers can be offered quickly.
2. 7 branches in different countries in the world for convenient sales and services.
3. Engineers available to solve problems.
4. 5 factories help order spare parts quickly and correctly.
We are one of the leading weaving machine manufacturers in the world more than 20 years.
YIGO Group consisted of
- Xiamen Yigo Industrial Co., Ltd.(export office)
- Yitai Technology Co., Ltd,
- Jinjiang Yitai Weaving Machine Making Co.,Ltd.
- Dongtai Knitting Machine Co., Ltd.,
- Jinjiang Baoya Textile Co.,Ltd.
Our factory is located in Jinjiang city with an area of 10,000 square meters. Products with CE and ISO:2000.Products include NEEDLE LOOM, JACQUARD LOOM, BRAIDING MACHINE, CROCHET KNITTING MACHINE, WEFT MACHINE, WARPING MACHINE, ROLLING MACHINE etc.
CE, BV, ISO9001
1. Are you a factory or trading company ?
We're a factory. Our factory located in Jinjiang city, it takes about 50 minutes from Jinjiang airport. And our office located in Xiamen city, beside the sea, takes about 20 minutes from Xiamen airport.
2. Can you make some change for me for my own design ?
Sure.we can make OEM and ODM machines for you as long as you can tell us your idea specifically or provide drawings.
3. Do you have any branches in the world, and how do you guarantee your quality ?
Yes, we have about 7 branches in different countries.
We're responsible for quality of the machine for 1 year.
And engineers will provide technical support.
